Nanostation M2 AirMax AP-CPE
|  |
- Performance Breakthrough :
150+ Mbps real outdoor throughput and up to 15km+ range. Featuring 2x2 MIMO technology, the new NanoStation links significantly faster and farther than ever before.
- New Leading-Edge Industrial Design:
The original NanoStation set the bar for the world's first low-cost and efficiently designed outdoor broadband CPE. The new NanoStation M and NanoStation Loco M take the same concept to the future with new redesigned sleek and elegant form-factors.
- Next-Gen Antenna Design:
New antenna array designs featuring 11dBi dual-polarity 11dBi at 2.4GHz wtih optimized cross-polarity isolation and in a compact form-factor.
- Dual Ethernet Connectivity:
The New NanoStation M provides a secondary ethernet port with software enabled POE output for seamless IP Video integration.
- Intelligent POE:
Remote hardware reset circuitry of NanoStation M allows for device to be reset remotely from power supply location. In addition, any NanoStation can easily become 802.3af 48V compliant through use of Ubiquiti's Instant 802.3af adapter.
- AirOS V:
Version 5 of Ubiquiti's AirOS builds upon the market leading intuitive user-interface loaded with advanced wireless configurations and routing functionality.
| System Information : |
|---|
| Processor Specs |
Atheros MIPS 24KC, 400MHz |
| Memory Information |
32MB SDRAM, 8MB Flash |
| Networking Interface |
2 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet Interface |
| Regulatory / Compliance information : |
|---|
| Wireless Approvals |
FCC Part 15.247, IC RS210, CE |
| RoHS Compliance |
YES |
| Physical - Electrical - Environmental : |
|---|
| Enclosure Size |
29.4 cm x 8 cm x 3cm |
| Weight |
0.4kg |
| Enclosure Characteristics |
Outdoor UV Stabalized Plastic |
| Mounting Kit |
Pole Mounting Kit included |
| Max Power Consumption |
8 Watts |
| Power Supply |
15V, 0.8A surge portection integrated POE adapter included |
| Power Method |
Passive Power over Ethernet (pairs 4,5+; 7,8 return) |
| Operating Temperature |
-30C to +80C |
| Operating Humidity |
5 to 95% Condensing |
| Shock and Vibration |
ETSI300-019-1.4 |
| INTEGRATED 2x2 MIMO ANTENNA : |
|---|
| Frequency Range |
2.32-2.55 GHz |
| Gain |
10.4-11.2 dBi |
| Polarization |
Dual Linear |
| Cross-pol Isolation |
23dB minimum |
| Max VSWR |
1.6:1 |
| H-pol Beamwidth |
55 deg. |
| V-pol Beamwidth |
53 deg. |
| Elevation Beamwidth |
27 deg. |
 Αναλυτικά χαρακτηριστικά Nanostation M2 AirMax AP-CPE
|
Όνομα:
Nanostation M2 AirMax AP-CPE |
Κωδικός:
NSM2 EU |
Τιμή:
160.00 € | Διαθεσιμότητα:
Διαθέσιμο Κατόπιν Παραγγελίας | | |  Προσθήκη στο καλάθι |
|
|
